Honda CLICK160 User Manual

Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.” 2 P. 81
#
Fuse Box Fuses
1. Remove the battery lid and the battery
cover from the step floor. 2 P. 88
2.
Pull the fuses out with the fuse puller in
back side of battery cover one by one
check for blown fuse. Always replace a
blown fuse with a spare fuse of the same
rating.
u Spare fuses are provided on back side
of the battery cover.
3. Install the battery lid and the battery
cover.
NOTICE
If a fuse fails repeatedly, you likely have an
electrical problem. Have your vehicle inspected
by your dealer.
20220404183646_32K2SD000_eng_BOOK Page 127 Monday, April 04 2022 18:39:28 JST
Electrical Trouble u Blown Fuse
Troubleshooting
124
Main fuse
Battery cover
Fuse puller
Spare fuses

Honda CLICK160 Specifications

General

Displacement	156.9 cc
Fuel System	PGM-FI (Programmed Fuel Injection)
Transmission	Automatic, V-Matic
Front Suspension	Telescopic Fork
Fuel Capacity	5.5 liters
Ignition	Full Transistorized
Starter	Electric
Seat Height	778 mm
Ground Clearance	138 mm
Engine Type	4-stroke, liquid-cooled
Front Brake	Hydraulic Disc
Rear Brake	Drum
Bore x Stroke	60.0 mm x 55.5 mm
Compression Ratio	12:1
Rear Tire	120/70-14 M/C 61P
Length x Width x Height	1, 929 mm x 1, 088 mm
Front Tire	100/80-14 M/C 48P
