Honda CLICK160 User Manual

Specifications
■ Main Components
Overall length 1,929 mm (75.9 in)
Overall width 678 mm (26.7 in)
Overall height 1,088 mm (42.8 in)
Wheelbase 1,278 mm (50.3 in)
Minimum ground
clearance
138 mm (5.4 in)
Caster angle 26º 0’
Trail 85 mm (3.3 in)
Curb weight 117 kg (258 lb)
Maximum weight
capacity
*1
129 kg (284 lb)
Maximum luggage
weight
Centre compartment 10 kg (22 lb)
Front box/Hook/
Inner rack
1.5 kg (3.3 lb)
Passenger capacity Rider and 1 passenger
Minimum turning radius 1.90 m (6.2 ft)
*1 : Including rider, passenger, all luggage, and accessories.
Displacement 156.93 cm
3
(9.573 cu-in)
Bore x stroke 60.000 x 55.502 mm (2.3622 x 2.1851 in)
Compression ratio 12.0:1
Fuel
Unleaded petrol
Recommended: 91 RON or higher
Fuel containing
alcohol
ETHANOL up to 10 % by volume
Tank capacity 5.5 L (1.45 US gal, 1.21 Imp gal)
Battery
YTZ6V 12 V-5.0 Ah (10 HR)
FTZ6V 12 V-5.0 Ah (10 HR)
Primary reduction V-Matic (2.52:1-0.82:1)
Final reduction 9.589
20220404183646_32K2SD000_eng_BOOK Page 142 Monday, April 04 2022 18:39:28 JST
Specifications
139

Honda CLICK160 Specifications

General

Displacement	156.9 cc
Fuel System	PGM-FI (Programmed Fuel Injection)
Transmission	Automatic, V-Matic
Front Suspension	Telescopic Fork
Fuel Capacity	5.5 liters
Ignition	Full Transistorized
Starter	Electric
Seat Height	778 mm
Ground Clearance	138 mm
Engine Type	4-stroke, liquid-cooled
Front Brake	Hydraulic Disc
Rear Brake	Drum
Bore x Stroke	60.0 mm x 55.5 mm
Compression Ratio	12:1
Rear Tire	120/70-14 M/C 61P
Length x Width x Height	1, 929 mm x 1, 088 mm
Front Tire	100/80-14 M/C 48P
