Honda crf250r 2012 User Manual

94 Servicing Your Honda
Wheels
Refer to Safety Precautions on page 23.
Keeping the wheels true (round) and maintaining
correct spoke tension is critical to safe
motorcycle operation. During the first few rides,
spokes will loosen more rapidly due to the initial
seating of the parts. Excessively loose spokes
may result in instability at high speeds and the
possible loss of control. It’s also important that
the rim locks are secure to prevent tire slippage.
It is not necessary to remove the wheels to
perform the recommended service in the
Maintenance Schedule (page 25). However,
information for wheel removal is provided for
emergency situations.
Wheel Rims & Spokes
(1) wheel rim (3) rim lock
(2) spoke
1. Inspect the wheel rims (1) and spokes (2) for
damage.
2. Tighten, any loose spokes and rim locks (3) to
the specified torque:
Front Spoke
:
2.7 lbf·ft (3.7 N·m, 0.4 kgf·m)
Rear Spoke :
2.7 lbf·ft (3.7 N·m, 0.4 kgf·m)
Rim Lock : 9 lbf·ft (12 N·m, 1.2 kgf·m)
3. Check wheel rim runout. If runout is
noticeable, see the Honda Service Manual for
inspection instructions.
Axles & Wheel Bearings
See the Honda Service Manual for inspection
information:
1. Check the axle shaft for runout.
2. Check the condition of the wheel bearings.
(1)
(3)
(2)

Honda crf250r 2012 Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	76.8mm x 53.8mm
Transmission	Close-ratio five-speed
Front Suspension Travel	12.2 inches
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/90-19
Seat Height	37.6 inches
Ground Clearance	13.2 inches
Fuel System	PGM-FI
Final Drive	Chain
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability
