Honda crf250r 2012 User Manual

34 Servicing Your Honda
Fuel Tank
Refer to Safety Precautions on page 23.
Removal
1. Remove the seat (page 33).
2. Remove the shroud A bolts and collars (1).
3. Remove the shroud B bolts (2) and shrouds (3).
7. Remove the fuel tank bolt and collar (7).
WARNING
Gasoline is highly flammable and
explosive.You can be burned or seriously
injured when handling fuel.
• Stop the engine and keep heat, sparks
and flame away.
• Handle fuel only outdoors.
• Wipe up spills immediately.
(8) fuel feed hose (11) fuel tank stopper cable
(10) fuel tank
10. Check for interference between the frame and
tank and adjust the cushion rubbers (12) if
necessary.
(1) shroud A bolts and collars (3) shrouds
(2) shroud B bolts
4. Install a hose clamp (4) to the breather tube
(5) and shut the hose clamp securely
(4) hose clamp (5) breather tube
5. Pull the breather tube (5) out of steering stem
nut.
6. Unhook the fuel tank band (6).
(5) breather tube
(6) fuel tank band
(7) fuel tank bolt and collar
8. Unhook the fuel feed hose (8) from the clamp
(9).
(12)
2.4 in (60 mm)
(12) cushion rubbers
(8) fuel feed hose (9) clamp
9. Pull the fuel tank (10) out of the frame and
hang it to the left of the frame.
Check the fuel tank stopper cable (11) for
deterioration, kinks or other damage.
Do not support the fuel tank by the fuel feed
hose (8).
(3)
(2)
(1)
(5)
(4)
(5)
(7)
(6)
(8)
(9)
(8)
(11)
(10)

Honda crf250r 2012 Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	76.8mm x 53.8mm
Transmission	Close-ratio five-speed
Front Suspension Travel	12.2 inches
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/90-19
Seat Height	37.6 inches
Ground Clearance	13.2 inches
Fuel System	PGM-FI
Final Drive	Chain
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability
