Honda crf250r 2012 User Manual

Driven chain
size/link
DID520DMA4–120RB
RK520TXZ-120RJ
Optional
Handlebar
lower holder
Standard 3 mm offset
no offset
FRAME Remarks
Driven sprocket
Standard
< >: Drive chain links
49 Teeth, Aluminum.
<116>
Optional 48 Teeth, Aluminum
50 Teeth, Aluminum
TOOLS Remarks
Pin spanner A
Air gauge For checking tire air pressure
Workstand
To adjust spring preload.
(two spanners required)
For maintenance
These parts and tools may be ordered from your
authorized dealer.
FRAME Remarks
Shock spring
Standard
Optional
Softer
Stiffer
Fork spring
Standard
The standard fork spring and shock spring
mounted on the motorcycle when it leaves the
factory are not marked. Before replacing the
springs, be sure to mark them so they can be
distinguished from other optional springs.
296.9 lbf/in (52.0 N/mm)
No mark
(factory products)
Red
paint
(aftermarket parts)
or
285.5 lbf/in (50.0 N/mm)
25.12 lbf/in (4.4 N/mm)
Blue
White
307.7 lbf/in (53.9 N/mm)
Red
Stiffer
Optional
Softer
23.98 lbf/in (4.2 N/mm)
26.20 lbf/in (4.59 N/mm)
2 scribe marks
1 scribe mark
No mark
156 Technical Information
Optional Parts List

Honda crf250r 2012 Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	76.8mm x 53.8mm
Transmission	Close-ratio five-speed
Front Suspension Travel	12.2 inches
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/90-19
Seat Height	37.6 inches
Ground Clearance	13.2 inches
Fuel System	PGM-FI
Final Drive	Chain
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability
