Instruments & Controls 9
Indicator
DTC Index
MIL blinks
1
2
7
8
9
MAP sensor circuit malfunction
MAP sensor performance problem
ECT sensor circuit malfunction
TP sensor circuit malfunction
IAT sensor circuit malfunction
12 Injector circuit malfunction
19 No.1 CKP sensor circuit malfunction
69 No.2 CKP sensor circuit malfunction
Engine operates normally
Engine operates normally
Hard start at a low temperature
Poor engine acceleration
Engine operates normally
• Engine does not start
• Injector, fuel pump and ignition shut down
• Engine does not start
• Injector, fuel pump and ignition shut down
• Engine does not start
• Injector, fuel pump and ignition shut down
Function Failure Symptom/Fail-safe Function
Should be serviced by your dealer, unless the owner has proper tools and is technically qualified.
The series of 12, 19, and 69 MIL blinks cannot be checked because the engine cannot be started.
If the engine does not start, check all connector connections and/or refer to an official Honda Service
Manual (page 160) for troubleshooting of the PGM-FI symptom.
Refer to MIL Blink Pattern on page 7.

Honda crf250r 2012 Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	76.8mm x 53.8mm
Transmission	Close-ratio five-speed
Front Suspension Travel	12.2 inches
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/90-19
Seat Height	37.6 inches
Ground Clearance	13.2 inches
Fuel System	PGM-FI
Final Drive	Chain
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability
