Honda crf250r 2012 User Manual

Clutch System
62 Servicing Your Honda
Refer to Safety Precautions on page 23.
Clutch Lever Adjustment
The distance between the tip of the clutch lever
and grip may be adjusted.
Make sure to adjust the clutch lever freeplay after
the clutch lever position adjustment or clutch
cable disconnected.
(1) lock nut (2) adjuster
1. Loosen the lock nut (1).
2. To position the clutch lever farther away from
the handgrip, turn the adjuster (2)
counterclockwise. To position the brake lever
closer to the handgrip, turn the adjuster
clockwise.
3. Tighten the lock nut.
(3) cable end adjuster
(+) increase freeplay
(–) decrease freeplay
5. Loosen the lock nut (4) and turn the integral
cable adjuster (5) to adjust the clutch lever
freeplay 3/8 – 13/16 in (10 – 20 mm) at the
tip of lever. Tighten the lock nut.
(1)
(2)
(3)
(–)
(+)
4. Turn the cable end adjuster (3) in direction (+)
until it seats lightly and then turn it out 5
turns.
(4)
(5)
(–)
(+)
(4) lock nut
(5) integral cable adjuster
(+) increase freeplay
(–) decrease freeplay
6. Adjust the cable end adjuster for minor
adjustement.
Clutch Lever Freeplay
(1) freeplay
Inspection
Check freeplay (1).
Freeplay:
3/8 – 13/16 in (10 – 20 mm)
If necessary, adjust to the specified range.
Improper freeplay adjustment can cause
premature clutch wear.
Make sure to adjust the clutch lever freeplay after
the clutch cable is disconnected.
(1)

Honda crf250r 2012 Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	76.8mm x 53.8mm
Transmission	Close-ratio five-speed
Front Suspension Travel	12.2 inches
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/90-19
Seat Height	37.6 inches
Ground Clearance	13.2 inches
Fuel System	PGM-FI
Final Drive	Chain
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability
