Honda crf250r 2012 User Manual

Servicing Your Honda 61
Engine Idle Speed
Refer to Safety Precautions on page 23.
Remember, idle speed adjustment is not a “cure-
all” for other problems in your engine’s PGM-FI
system. Adjusting the idle will not compensate
for a fault elsewhere.
The engine must be at normal operating
temperature for accurate idle speed adjustment.
When pushed in, the fast idle knob acts as the
idle adjust screw.
Turning it counterclockwise results in a
faster/higher idle speed.
Turning it clockwise results in a slower/lower
idle speed.
Idle Speed Adjustment
1. If the engine is cold, start it and warm it up 3
minutes. Then shut it off.
2. Connect a tachometer to the engine.
3. Shift the transmission into neutral. Start the
engine.
4. Keep the motorcycle in an upright position.
5. Adjust idle speed with the fast idle knob (1).
Idle speed:
2,000 ± 100 rpm
(1)
(+)
(–)
(1) fast idle knob
(+) increase
(–) decrease

Honda crf250r 2012 Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	76.8mm x 53.8mm
Transmission	Close-ratio five-speed
Front Suspension Travel	12.2 inches
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/90-19
Seat Height	37.6 inches
Ground Clearance	13.2 inches
Fuel System	PGM-FI
Final Drive	Chain
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability
