Honda EU70is User Manual

63
SERVICING YOUR GENERATOR
Battery Removal
Battery posts, terminals, and related accessories contain lead and lead
compounds. Wash hands after handling.
1.Lift the handle upward. The lock levers will lock and secure the 
handle in place.
2.Loosen the cover screw and remove the battery maintenance cover.
HANDLE
HANDLE LOCK LEVER
COVER SCREW
BATTERY MAINTENANCE COVER
36Z376000.book 63 ページ ２０１４年９月１９日 金曜日 午後６時２６分

Honda EU70is Specifications

General

Model	EU70is
Type	Inverter
Maximum AC Output	7000 VA
Rated AC Output	5500 VA
Engine	GX390
Engine Displacement	389 cc
Fuel Type	Gasoline
Run Time per Tankful	6.5 hours at rated load
Starter System	Electric
DC Output	12V, 8.3A
Run Time at 1/4 Load	18 hours
Noise Level	52 dB(A) at 1/4 load
Rated Voltage	220-240V
