Honda TRAIL125 2023 User Manual

Description
2021-2023 Trail125 Service Manual
Common Service Manual (61CSM00)
USA
Winter Storage Guide (S9507)
2023 Trail125 Owner’s Manual
Authorized Manuals
USA
The Service Manual used by your
authorized dealer is available from your Honda
dealer or Helm, Inc.
Canada
See your dealer to order authorized
manuals.
Also available, but not necessary to service your
model, is the Honda Common Service Manual,
which explains basic service information for
various systems on Honda motorcycles,
scooters, ATV, and SxS.
USA
The Winter Storage Guide in conjunction
with the Owner's Manual and Service Manual
can help you prepare your Honda motorcycle,
scooter, ATV, and SxS for winter storage.
These Honda manuals are written for the
professional technician. However, if you possess
the proper tools, observe the safety standards,
and are mechanically capable, you should find
them easy to use.
Special Honda tools are necessary for some
procedures.
USA
Order online: www.helminc.com
Order Toll Free: 1-888-CYCLE93
(1-888-292-5393)
(NOTE: For Credit Card Orders Only)
Monday - Friday 8:00 AM - 6:00 PM ET
Authorized Manuals
Information
102

Honda TRAIL125 2023 Specifications

General

Engine Type	124cc air-cooled single-cylinder four-stroke
Bore and Stroke	52.4mm x 57.9mm
Compression Ratio	10.0:1
Final Drive	Chain
Front Tire	80/90-17
Rear Tire	80/90-17
Rake (Caster Angle)	27°
Trail	3.1 inches
Wheelbase	49.4 inches
Seat Height	31.5 inches
Curb Weight	259 pounds
Fuel Capacity	1.4 gallons
Induction	PGM-FI
Ignition	Fully transistorized
Transmission	Four-speed
Front Suspension	Telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 220mm disc
Rear Brake	Single 190mm disc
