Honda TRAIL125 2023 User Manual

UPPER
Brakes
Checking Brake Fluid
1. Place your vehicle in an upright position
on a firm, level surface.
2.
Front
Check that the brake fluid reservoir
is horizontal and that the fluid level is
above the LOWER level mark.
Rear
Check that the brake fluid reservoir is
horizontal and that the fluid level is between
the LOWER level and UPPER level marks.
If the brake fluid level in either reservoir is
below the LOWER level mark or the brake
lever and pedal freeplay becomes excessive,
inspect the brake pads for wear.
If the brake pads are not worn, you most
likely have a leak. Have your vehicle
inspected by your dealer.
Maintenance
68
Front brake fluid reservoir
LOWER level mark
UPPER level
mark
LOWER level
mark
Rear brake fluid
reservoir
Front Rear

Honda TRAIL125 2023 Specifications

General

Engine Type	124cc air-cooled single-cylinder four-stroke
Bore and Stroke	52.4mm x 57.9mm
Compression Ratio	10.0:1
Final Drive	Chain
Front Tire	80/90-17
Rear Tire	80/90-17
Rake (Caster Angle)	27°
Trail	3.1 inches
Wheelbase	49.4 inches
Seat Height	31.5 inches
Curb Weight	259 pounds
Fuel Capacity	1.4 gallons
Induction	PGM-FI
Ignition	Fully transistorized
Transmission	Four-speed
Front Suspension	Telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 220mm disc
Rear Brake	Single 190mm disc
