Honda TRAIL125 2023 User Manual

Spark Arrester
Cleaning the Spark Arrester
Regular servicing prevents carbon buildup
(which can diminish engine performance)
and also complies with USDA regulations for
regular maintenance to assure proper
function. The spark arrester prevents random
sparks from the combustion process in your
engine from reaching the environment.
1. Allow the engine and muffler to cool.
2.
Remove the muffler cover bolts and
muffler cover from the muffler.
3. Remove the tail cap cover bolts and tail
cap cover from the muffler.
4. Remove the spark arrester mounting
bolts, spark arrester and gasket from the
muffler.
Maintenance
64
Tail cap
cover bolts
Tail cap cover
Muffler
cover bolts
Muffler cover
GasketSpark arrester
Spark arrester
mounting bolts
Muffler

Honda TRAIL125 2023 Specifications

General

Engine Type	124cc air-cooled single-cylinder four-stroke
Bore and Stroke	52.4mm x 57.9mm
Compression Ratio	10.0:1
Final Drive	Chain
Front Tire	80/90-17
Rear Tire	80/90-17
Rake (Caster Angle)	27°
Trail	3.1 inches
Wheelbase	49.4 inches
Seat Height	31.5 inches
Curb Weight	259 pounds
Fuel Capacity	1.4 gallons
Induction	PGM-FI
Ignition	Fully transistorized
Transmission	Four-speed
Front Suspension	Telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 220mm disc
Rear Brake	Single 190mm disc
