Honda TRAIL125 2023 User Manual

Specifications
■ Main Components
Overall length 77.4 in (1,965 mm)
Overall width 31.7 in (805 mm)
Overall height 42.7 in (1,085 mm)
Wheelbase 49.6 in (1,260 mm)
Minimum ground clearance 6.7 in (170 mm)
Caster angle 27°
Trail 3.1 in (80 mm)
Curb weight 256 lb (116 kg)
Maximum weight capacity
*1
265 lb (120 kg)
Maximum luggage weight 44.0 lb (20.0 kg)
Passenger capacity Rider only
Minimum turning radius 5.9 ft (1.80 m)
*1 : Including rider and accessories.
Displacement 7.6 cu-in (124 cm
3
)
Bore x stroke 1.97 x 2.48 in (50.0 x 63.1 mm)
Compression
ratio
10.0 : 1
Fuel
Unleaded gasoline
Recommended: 86 PON or higher
Tank capacity 1.40 US gal (5.3 L)
Battery
YTZ5S
12 V-3.5 Ah (10 HR)
Gear ratio
1st 2.500
2nd 1.550
3rd 1.150
4th 0.923
Reduction ratio
(primary / final)
3.421 / 2.714
Specifications
110

Honda TRAIL125 2023 Specifications

General

Engine Type	124cc air-cooled single-cylinder four-stroke
Bore and Stroke	52.4mm x 57.9mm
Compression Ratio	10.0:1
Final Drive	Chain
Front Tire	80/90-17
Rear Tire	80/90-17
Rake (Caster Angle)	27°
Trail	3.1 inches
Wheelbase	49.4 inches
Seat Height	31.5 inches
Curb Weight	259 pounds
Fuel Capacity	1.4 gallons
Induction	PGM-FI
Ignition	Fully transistorized
Transmission	Four-speed
Front Suspension	Telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 220mm disc
Rear Brake	Single 190mm disc
