Honda VFR1200F User Manual

107
Troubleshooting
Electrical Trouble
a
Blown Fuse
Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.”
P.53
❙
Fuse Box Fuses
1. Remove the seat.
P.59
2. Remove the fuse box cover.
3. Pull the main fuse A and other fuses out
one by one with the fuse puller in the
fuse box cover and check for a blown
fuse. Always replace a blown fuse with a
spare of the same rating.
4. Reinstall the fuse box cover.
5. Reinstall the seat.
Fuse puller Fuse box cover
Spare fuses Main fuse A
31MGE601.indb 107 2010/03/08 18:05:53

Honda VFR1200F Specifications

General

Bore and Stroke	81mm x 60mm
Compression Ratio	12.0:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	Shaft
Front Tire	120/70 ZR17 radial
Rear Tire	190/55 ZR17 radial
Wheelbase	60.8 inches
Seat Height	32.1 inches
Fuel Capacity	4.9 gallons
Engine Type	1, 237cc liquid-cooled 76° V-4
Fuel System	PGM-FI
Front Suspension	43mm inverted cartridge fork with spring preload adjustability; 4.7 inches travel
Rear Suspension	5.1 inches travel
Front Brake	Dual 320mm discs with 6-piston calipers, ABS
Rear Brake	276mm disc with 2-piston caliper, ABS
Curb Weight	591 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride)
