Front
73
Maintenance
Brakes/Clutch
Checking Brake Fluid
1. Place your motorcycle in an upright
position on a firm, level surface.
2.
Front
Check that the brake fluid reservoir
cap is horizontal and that the fluid level is
above the lower level mark.
3.
Rear
Remove the seat.
P.59
4.
Rear
Check that the brake fluid reservoir
is horizontal and that the level is between
the lower level and upper level marks.
If the brake fluid level in either reservoir is
below the lower level mark or the brake
lever and pedal freeplay becomes excessive,
inspect the brake pads for wear. If the brake
pads are not worn, you most likely have a
leak. Have your motorcycle inspected by
your dealer.
Front brake fluid reservoir Rear brake fluid reservoir
Lower
level
mark
Upper level
mark
Lower level
mark
Rear
31MGE601.indb 73 2010/03/08 18:05:48

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda VFR1200F and is the answer not in the manual?

Honda VFR1200F Specifications

General IconGeneral
Bore and Stroke81mm x 60mm
Compression Ratio12.0:1
IgnitionComputer-controlled digital transistorized with electronic advance
Transmission6-speed
Final DriveShaft
Front Tire120/70 ZR17 radial
Rear Tire190/55 ZR17 radial
Wheelbase60.8 inches
Seat Height32.1 inches
Fuel Capacity4.9 gallons
Engine Type1, 237cc liquid-cooled 76° V-4
Fuel SystemPGM-FI
Front Suspension43mm inverted cartridge fork with spring preload adjustability; 4.7 inches travel
Rear Suspension5.1 inches travel
Front BrakeDual 320mm discs with 6-piston calipers, ABS
Rear Brake276mm disc with 2-piston caliper, ABS
Curb Weight591 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride)
