Honda VFR1200F User Manual

133
Specifications
Specifications
*1 Including rider, passenger, all luggage, and accessories
*2 Includes the weight of the luggage and added accessories.
■ Main Components
Overall length 88.6 in (2,250 mm)
Overall width
VFR1200F 29.7 in (755 mm)
VFR1200FD 29.1 in (740 mm)
Overall height 48.0 in (1,220 mm)
Wheelbase 60.8 in (1,545 mm)
Minimum ground
clearance
4.9 in (125 mm)
Caster angle 25º 30’
Trail 4.0 in (101 mm)
Curb weight
VFR1200F 591 lb (268 kg)
VFR1200FD 613 lb (278 kg)
Maximum weight
capacity
*1
402 lb (182 kg)
Maximum luggage
weight
*2
101 lb (46 kg)
Luggage 46 lb (21 kg)
Accessories 55 lb (25 kg)
Passenger capacity Rider and 1 passenger
Minimum turning
radius
11.6 ft (3.5 m)
Displacement 75.45 cu-in (1,237 cm
3
)
Bore x stroke 3.19 × 2.36 in (81.0 x 60.0 mm)
Compression ratio 12.0:1
Fuel
Unleaded gasoline
Recommended fuel octane number:
Pump Octane Number (PON) 91 or higher.
Tank capacity 4.89 US gal (18.5 litres)
Battery 12V-11.2Ah
Gear ratios
VFR1200F
1st 2.600
2nd 1.736
3rd 1.363
4th 1.160
5th 1.032
6th 0.939
VFR1200FD
1st 2.466
2nd 1.789
3rd 1.409
4th 1.160
5th 1.032
6th 0.939
Reduction ratios
(primary / secondary / final)
VFR1200F
1.738 / 1.060 / 2.545
VFR1200FD
1.738 / 1.063 / 2.545
31MGE601.indb 133 2010/03/08 18:05:55

Honda VFR1200F Specifications

General

Bore and Stroke	81mm x 60mm
Compression Ratio	12.0:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	Shaft
Front Tire	120/70 ZR17 radial
Rear Tire	190/55 ZR17 radial
Wheelbase	60.8 inches
Seat Height	32.1 inches
Fuel Capacity	4.9 gallons
Engine Type	1, 237cc liquid-cooled 76° V-4
Fuel System	PGM-FI
Front Suspension	43mm inverted cartridge fork with spring preload adjustability; 4.7 inches travel
Rear Suspension	5.1 inches travel
Front Brake	Dual 320mm discs with 6-piston calipers, ABS
Rear Brake	276mm disc with 2-piston caliper, ABS
Curb Weight	591 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride)
