Honda VFR1200F User Manual

61
Maintenance
Removing & Installing Body Components
a
Right Engine Heat Guard & Right Under Fairing
Right Engine Heat Guard &
Right Under Fairing
The right engine heat guard must be
opened to service the coolant reserve tank
or to check the engine number.
(VFR1200F)
The right under fairing must be removed to
service the engine oil filter.
(VFR1200FD)
The right under fairing must be removed to
service the engine oil filter and the clutch oil
filter.
❙
Removal
1. Open the right engine heat guard.
Right engine
heat guard
continued
31MGE601.indb 61 2010/03/08 18:05:46

Honda VFR1200F Specifications

General

Bore and Stroke	81mm x 60mm
Compression Ratio	12.0:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	Shaft
Front Tire	120/70 ZR17 radial
Rear Tire	190/55 ZR17 radial
Wheelbase	60.8 inches
Seat Height	32.1 inches
Fuel Capacity	4.9 gallons
Engine Type	1, 237cc liquid-cooled 76° V-4
Fuel System	PGM-FI
Front Suspension	43mm inverted cartridge fork with spring preload adjustability; 4.7 inches travel
Rear Suspension	5.1 inches travel
Front Brake	Dual 320mm discs with 6-piston calipers, ABS
Rear Brake	276mm disc with 2-piston caliper, ABS
Curb Weight	591 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride)
