Honda VFR1200F User Manual

60
MaintenanceMaintenance
Removing & Installing Body Components
a
Clips
Clips
The clips must be removed to remove the
right rear fairing.
❙
Removal
1. Press down on the center pin to release
the lock.
2. Pull the clip out of the hole.
❙
Installation
1. Push the bottom of the center pin.
2. Insert the clip into the hole.
3. Press down on the center pin to lock the
clip.
Final Gear Cover
The final gear cover must be opened to
drain the final gear oil.
❙
Removal
1. Remove the bolts.
2. Open the final gear cover.
❙
Installation
Install the parts in the reverse order of removal.
Center
pin
Final gear
cover
Bolts
31MGE601.indb 60 2010/03/08 18:05:46

Honda VFR1200F Specifications

General

Bore and Stroke	81mm x 60mm
Compression Ratio	12.0:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	Shaft
Front Tire	120/70 ZR17 radial
Rear Tire	190/55 ZR17 radial
Wheelbase	60.8 inches
Seat Height	32.1 inches
Fuel Capacity	4.9 gallons
Engine Type	1, 237cc liquid-cooled 76° V-4
Fuel System	PGM-FI
Front Suspension	43mm inverted cartridge fork with spring preload adjustability; 4.7 inches travel
Rear Suspension	5.1 inches travel
Front Brake	Dual 320mm discs with 6-piston calipers, ABS
Rear Brake	276mm disc with 2-piston caliper, ABS
Curb Weight	591 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride)
