Honda XR150 2018 User Manual

Tool
The tool kit is stored in the tool box. 2 P. 28
You can perform some roadside repairs, minor
adjustments and parts replacement with the
provided tools.
● Spark plug wrench
● 10 × 12 mm Open end wrench
● 14 × 17 mm Open end wrench
● No. 2 Phillips screwdriver
● No. 2 Screwdriver
● Screwdriver handle
● Extension bar
● 24 mm Box end wrench
20171023164032_32KRHH100_eng_BOOK Page 50 Monday, October 23 2017 17:21:44 JST
Maintenance
47

Honda XR150 2018 Specifications

General

Displacement	149.2 cc
Bore x Stroke	57.3 mm x 57.8 mm
Compression Ratio	9.5:1
Fuel System	Carburetor
Ignition	CDI
Transmission	5-speed
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Fuel Tank Capacity	12 liters
Seat Height	825 mm
Curb Weight	129 kg
Max Torque	12.5 Nm @ 6, 000 rpm
Ground Clearance	245 mm
Engine Type	Air-cooled, 4-stroke, OHC
Length x Width x Height	1, 125 mm
