Honda XR150 2018 User Manual

Side Cover
The right and left side covers can be
removed in the same manner.
#
Removal
1. Remove the bolt and collar.
2. Remove the prongs from the grommets.
3. Remove the side cover.
#
Installation
Install the parts in the reverse order of
removal.
20171023164032_32KRHH100_eng_BOOK Page 53 Monday, October 23 2017 17:21:44 JST
Removing & Installing Body Components u Side Cover
Maintenance
50
Prong
Grommets
Bolt
Side cover
Collar
Prong
Left side

Honda XR150 2018 Specifications

General

Displacement	149.2 cc
Bore x Stroke	57.3 mm x 57.8 mm
Compression Ratio	9.5:1
Fuel System	Carburetor
Ignition	CDI
Transmission	5-speed
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Fuel Tank Capacity	12 liters
Seat Height	825 mm
Curb Weight	129 kg
Max Torque	12.5 Nm @ 6, 000 rpm
Ground Clearance	245 mm
Engine Type	Air-cooled, 4-stroke, OHC
Length x Width x Height	1, 125 mm
