Honda XR150 2018 User Manual

Crankcase Breather
Cleaning the Crankcase
Breather
1. Place a suitable container under the
crankcase breather tube.
2. Remove the crankcase breather tube plug
from the tube.
3.
Drain deposits into a suitable container.
4.
Install the crankcase breather tube plug.
20171023164032_32KRHH100_eng_BOOK Page 77 Monday, October 23 2017 17:21:44 JST
Maintenance
74
Crankcase breather tube plug

Honda XR150 2018 Specifications

General

Displacement	149.2 cc
Bore x Stroke	57.3 mm x 57.8 mm
Compression Ratio	9.5:1
Fuel System	Carburetor
Ignition	CDI
Transmission	5-speed
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Fuel Tank Capacity	12 liters
Seat Height	825 mm
Curb Weight	129 kg
Max Torque	12.5 Nm @ 6, 000 rpm
Ground Clearance	245 mm
Engine Type	Air-cooled, 4-stroke, OHC
Length x Width x Height	1, 125 mm
