Storing Your Motorcycle
If you store your motorcycle outdoors, you
should consider using a full-body motorcycle
cover.
If you won't be riding for an extended period,
follow these guidelines:
Wash your motorcycle and wax all painted
surfaces (except mat painted surfaces). Coat
chrome pieces with rust-inhibiting oil.
Lubricate the drive chain. 2 P. 41
Place your motorcycle on a maintenance
stand and position a block so that both tyres
are off the ground.
After rain, remove the body cover and allow
the motorcycle to dry.
Remove the battery (2 P. 48) to prevent
discharge. Fully charge the battery and then
place it in a shaded, well-ventilated area.
u If you leave the battery in place,
disconnect the negative - terminal to
prevent discharge.
After removing your motorcycle from storage,
inspect all maintenance items required by the
Maintenance Schedule.
20171023164032_32KRHH100_eng_BOOK Page 98 Monday, October 23 2017 17:21:44 JST
Storing Your Motorcycle
Information
95

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda XR150 2018 and is the answer not in the manual?

Honda XR150 2018 Specifications

General IconGeneral
Displacement149.2 cc
Bore x Stroke57.3 mm x 57.8 mm
Compression Ratio9.5:1
Fuel SystemCarburetor
IgnitionCDI
Transmission5-speed
Front SuspensionTelescopic fork
Rear SuspensionMonoshock
Front BrakeDisc
Rear BrakeDrum
Front Tire90/90-19
Rear Tire110/90-17
Fuel Tank Capacity12 liters
Seat Height825 mm
Curb Weight129 kg
Max Torque12.5 Nm @ 6, 000 rpm
Ground Clearance245 mm
Engine TypeAir-cooled, 4-stroke, OHC
Length x Width x Height1, 125 mm
