Honda XR150 2018 User Manual

Other Adjustments
Adjusting the Headlight Aim
You can adjust vertical aim of the headlight
for proper alignment. Turn the screw in or
out as necessary using provided Phillips
screwdriver (2 P. 47).
Obey local laws and regulations.
20171023164032_32KRHH100_eng_BOOK Page 78 Monday, October 23 2017 17:21:44 JST
Maintenance
75
Raise
Lower

Honda XR150 2018 Specifications

General

Displacement	149.2 cc
Bore x Stroke	57.3 mm x 57.8 mm
Compression Ratio	9.5:1
Fuel System	Carburetor
Ignition	CDI
Transmission	5-speed
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Fuel Tank Capacity	12 liters
Seat Height	825 mm
Curb Weight	129 kg
Max Torque	12.5 Nm @ 6, 000 rpm
Ground Clearance	245 mm
Engine Type	Air-cooled, 4-stroke, OHC
Length x Width x Height	1, 125 mm
