System Overview LION System
EN1Z-0921GE51 R0709 4
System Overview
System Architecture
An LION System consists of the CLLIONLC01 Controller and various I/O modules.
The CLLIONLC01 Controller provides interface connections, which allow connection to external systems.
Auxiliary parts enable special features.
Panel Bus (<40 m)
CLLIONLC01 + CLIOxx
CLMMI00N22 or CLMMI00N31MODEM
LonWorks Bus
XFCLxxxXFCxxx SERVAL
LonWorks I/O (CLIOLxx)
Panel I/O (CLIOPxx)
C-Bus
existing XL500
controllers
Fig. 1 LION System architecture
Controller I/O Modules
Fig. 2 CLLIONLC01 Controller and I/O modules
