List of codes
Devices
1-RF Sensors (type D): DO800M, DODT800M, DF8M, DET8M, IR8M, IRPI8M, DFO800M,
CAMIR, CAMIR-N, IRVPI800M
Parameter
Short
Addr.
Long
Address
Values
Defaults
Partition
101
1323
0 = Total
1 = Partial Set
2 = Annex
3 = 24/24
D0800M = 1
IR8M = 0
IRPI8M = 0
Trigger condition
102
1425
0 = Immediate
1 = Delayed
2 = Mixed
3 = Exit door*
D0800M = 3
IR8M = 0
IRPI8M = 0
Function
103
1527
0 = Intrusion
1 = Technical
2 = Pre-alarm
3 = Perimeter
5 = Fire
6 = Driver
0
Chime
104
19 429
0 = Inactive
1 = Active
0
Transmission
111
2120
0 = OFF
1 = Alarm/End
2 = Alarm
Channels 1 – 10 = 2
Channels 17 – 18 = 1
Alarm code
(1st protocol)
112
2646
3 digits
Channels 1 – 10 = 130
Channels 17 – 18 = 110
End alarm code
(1st protocol)
113
2748
3 digits
Channels 1 – 10 = 130
Channels 17 – 18 = 110
Frequently used sensor
105
19 728
0 = Disabled
1 = Enabled
0
* software version K only
2-RF LCD Keypad (Type K16): TCU (all versions)
Partition
201
18 128
0 = Total
2 = Annex
3 = Total + Annex
0
Alert button
202
18 221
0 = Inactive
13 = Alert 1
14 = Alert 2
15 = Alert 3
0
3-RF LED Keypads (Type K5 and K9) CLI810HF and CSK800HF-B
Partition
301
1323
0 = Total
2 = Annex
3 = Total + Annex
0
Alert button
302
1425
0 = Inactive
1 = Alert 1
2 = Alert 2
3 = Alert 3
4 = Chime
1
