PLUMBING
Water Supply and Drain Connections
STEP ONE: Connect the Water Supply
Use hot or cold water.
Cut the water line so it reaches from the humidifier to
the main water supply tap
Insert the water line into the humidifier supply fitting.
Insert it fully, and apply modest pull pressure to
ensure a tight fit.
STEP TWO: Tap into a Water Line
Consult local codes for proper plumbing.s
Use the saddle valve provided or a T-fitting and s
manual shutoff valve to tap into the water line.
Refer to the literature included with the valve you s
chose and the local plumbing codes. Use proper
technique for the valve.
Connect the other end of the humidifier water line s
to the water valve.
Saddle Valve
T-fitting
Water Supply
Line
Manual Shutoff
Valve
M29605
2
1
Humidifier 69-2413EF—01
13
