RP-2002 Series Manual — P/N 53039:E6 1/26/2017 101
Template 1: Cross-Zone System - With Horn FACP Configuration Templates
B.1 Template 1: Cross-Zone System - With Horn
Table Legend:
X = direct correlation between Input Zone and Output Circuit (input zone activation will turn on
corresponding output circuit after any applicable delays).
Xc = cross-zone output where X indicates a direct correlation between Input Zone and Output Cir-
cuit (input zone activation will activate the corresponding output circuit) and c indicates that the
output circuit will indicate when one or more inputs of a cross-zoned group have been activated
(refer to “Cross-Zone for Release Circuit 1 or Release Circuit 2:” on page 61).
Cn = cross-zone inputs where n is the number of the Release Circuit. All inputs with the same
Release Circuit number must be active at the same time to turn on the corresponding Release output
circuit.
Input Zone Types:
• Zone 1 = circuit with type code of 2-wire smoke
• Zone 2 = circuit with type code of 2-wire smoke
• Zone 3 = circuit with type code Manual Release - activation will cause an immediate agent
release
• Zone 4 = circuit with type code of Abort Release Switch - programmed for UL Abort Type
operation (refer to “Abort Type” on page 65)
• Zone 5 = circuit with type code of Pull Station
• Zone 6 = circuit with type code of Supervisory
Output Circuit Types:
• Output 1 = Release Circuit 1 - Unsupervised for shorts
• Output 2 = Horn NAC - silenceable, programmed for cross-zone coded operation for Release
Circuit 1 (refer to Cross Zone in the section titled “Coded NAC Operation” on page 85
• Output 3 = Alarm NAC - silenceable, coded for steady on
• Output 4 = Alarm NAC - silenceable, coded for steady on
Timers
• Pre-Discharge Delay - set for 30 seconds
• Discharge - set for 1 minute
• Waterflow Delay Timer - set for 90 seconds
• AC Loss Delay Timer - set for 2 hours
Template 1: Cross-Zone System with Horn
INPUT ZONES
12 345 6
OUTPUT CIRCUITS
2-WIRE
SMOKE
2-WIRE
SMOKE
MANUAL
RELEASE
ABORT
PULL
STATION
SUPERVISORY
#1 RELEASE CIRCUIT 1
C1 C1 X X X
#2 HORN NAC
Xc Xc X
#3 ALARM NAC
X
#4 ALARM NAC
XX X
To Next Page
