Camera Specifications | 101
800-21358 - A - 10/2015
HBD1PR1/HBD3PR1/HBD3PR2 Bullet Cameras
Table B-2 HBD1PR1/HBD3PR1/HBD3PR2 Specifications
Camera
Image Sensor HBD1PR1: 1/3″ 1.3 megapixel progressive scan CMOS
HBD3PR1/HBD3PR2: 1/3″ 3 megapixel progressive scan CMOS
Max. Effective Pixels (H×V) HBD1PR1: 1280×960 (1.3 MP)
HBD3PR1/HBD3PR2: 2304×1296 (3 MP)
Min. Illumination HBD1PR1: 0.08 lux @ F2.1 (Color)/0 lux (B/W with IR LEDs on)
HBD3PR1: 0.045 lux @ F2.1 (Color)/0 lux (B/W with IR LEDs on)
HBD3PR3: 0.1 lux @ F1.4 (Color)/0 lux (B/W with IR LEDs on)
Lens HBD1PR1/HBD3PR1: Fixed, 3.6 mm @ F2.1
HBD3PR3: Motorized focus/zoom, 2.8–12 mm @ F1.4
Horizontal Angle of View HBD1PR1: 71°
HBD3PR1: 81°
HBD3PR3: 86°–28°
Automatic Electronic Shutter HBD1PR1: 1/3–1/30000 s
HBD3PR1: 1–1/100000 s
HBD3PR3: 1/3(4)–1/100000 s
S/N Ratio >50 dB
IR Range Up to 100 ft (30 m), depending on scene reflectance
Day/Night Auto(ICR)/Color/BW
BLC/WDR BLC/HLC/DWDR
White Balance Auto/Manual
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detection Up to 4 areas
Privacy Masking Up to 4 areas
Video
Compression H.264/H.264H/H.264B/MJPEG
Frame Rate HBD1PR1: 25/30 fps @ 1280×960 (1.3 MP), 1280×720 (720p), 704×576/704×480 (D1),
352×288/352×240 (CIF)
HBD3PR1/HBD3PR2: 20 fps @ 2304×1296 (3 MP); 25/30 fps @ 1920×1080(1080p), 1280×720
(720p), 704×576/704×480 (D1), 352×288/352×240 (CIF)
Bit Rate (H.264) 4–8192 kbps
Local Storage HBD3PR2: microSD, 128 GB max.
Network
Ethernet RJ-45 (10/100Base-T)
Supported Protocols IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,
PPPoE, DDNS, FTP, IP Filter, QoS
Compatibility ONVIF Profile S, CGI
User Access 20 users max.
Mobile App HonView Touch for iPhone, Android Phone and Tablet
