Configuring Events and Alarms | 87
800-21358 - A - 10/2015
Configuring the Motion Detection Area
Figure 6-3 Configuring the Motion Detection Area
Table 6-2 Motion Detection Area Configurations
Parameter Function
Sensitivity Adjust the brightness sensitivity. You might need to increase the
brightness sensitivity to trigger motion detection. You can
configure up to four areas. The sensitivity ranges from 0 to 100. We
recommend that you choose a sensitivity between 30 to 70. The
default is 50.
Threshold The threshold determines how much change in a scene is required
to trigger an alarm. The lower the threshold setting, the easier it is
to trigger a motion detection alarm. You can configure up to four
areas. The sensitivity ranges from 0 to 100. We recommend that
you choose a sensitivity between 10 to 50.
Delete All Delete all motion detection areas.
Delete Delete the selected motion detection area.
