PW7K1R1E Wiring and Setup
DIP Switch Configuration
PW7K1R1E OSDP Reader Interface, Configuration, and Installation Guide, Document 800-26498 13
2.4 DIP Switch Configuration
The four switches on S1 DIP switch are used to configure the operating mode of the
PW7K1R1E. DIP switches are read on power-up except where noted.
All other switch settings are unassigned and reserved for future use. X = don’t care.
2.5 Factory Default Communication Parameters
2.6 Bulk Erase
The bulk erase function can be used for the following purposes:
• Erase all configuration, sets PW7K1R1E to OEM setting (sanitize board).
• Restore to OEM default parameters.
2.7 Bulk Erase Steps
Do not remove power during steps 4-6.
1. Set S1 DIP switches to: 1 & 2 “ON”, 3 & 4 “OFF”.
2. Apply power to the PW7K1R1E.
3. Watch for LEDs 1 & 2 and 3 & 4 to alternately flash at a 0.5 second rate.
1 2 3 4 Definitions
OFF OFF OFF OFF Normal operating mode.
ON X OFF OFF
After initialization, enable default User Name (admin) and
Password (password). The switch is read on the fly, no need
to reboot. See IT Security section for additional information
OFF ON OFF OFF Use factory default communication parameters.
ON ON OFF OFF Use OEM default communication parameters. Contact
system manufacture for details. See Bulk Erase below.
ON ON OFF OFF Bulk Erase prompt mode at power up. See Bulk Erase
section.
Table 3: Factory Default Communication Parameters
Network : static IP address: 192.168.0.251
Subnet Mask : 255.255.0.0
Default Gateway :192.168.0.1
