PW7K1R1E Wiring and Setup
Warning
Figure 2-7: Mounting Plate Dimensions
2.17 Warning
Mercury Security warrants the product is free from defects in material and
workmanship under normal use and service with proper maintenance for one year
from the date of factory shipment. Mercury Security assumes no responsibility for
products damaged by improper handling or installation. This warranty is limited to the
repair or replacement of the defective unit.
There are no expressed warranties other than set forth herein. Mercury Security does
not make, nor intends, nor does it authorize any agent or representative to make any
other warranties, or implied warranties, and expressly excludes and disclaims all
implied warranties of merchantability or fitness for a particular purpose.
All returns must be accompanied by a Return Material Authorization (RMA) number
obtained from customer service, and prepaid postage and insurance.
3.85 [97.8]
2.35 [59.7]
5.50 [139.7]
3.63 [92.1]
3.30 [83.8]
3.63 [92.1]
Ø0.16 [Ø4.0]
MR50 MGT HOLES
4PL
Ø0.16 [Ø4.0]
3-GANG MGT HOLES
4PL
