TEMPERATURE TABLES
ON - OFF DAMPER TEMPERATURE TABLE
FREEZER CONTROL TABLE
REFRIGERATOR Temperature Sensor
Refrigerator Display Damper (Baffle) ON (°C) Damper (Baffle) OFF (°C)
67.55.5
56.54.5
45.03.5
34.02.5
23.01.5
Super Cool
Any of the above 3.0 1.5
FREEZER Temperature Sensor
Freezer Display Compressor ON (°C) Compressor OFF (°C)
-17 -17 -19
-18 -18 -20
-19 -19 -21
-20 -20 -22
-21 -21.5 -23.5
-22 -22.5 -24.5
-23 -23.5 -25.5
-24 -24.5 -26.5
Super Freeze
Any of the above Continuous Run
