Indesit Company
Service Manual UK English
SPECIFICATIONS
GENERAL:
Manufactured in: Italy
Appliance Type: Side by Side
Static / No- Frost: No-Frost
Door Hinging - Freezer L/H & Fridge R/H
Reversible: No
Plug/Cable: UK / 1.6m
Water Pipe: 1.65m
Noise Level: 'A' band models ~ 45dB
Climate Class: (Rating Plate) N.ST = 16°C to 38°C
Refrigeration Type: No-Frost - Fin On Tube (FOT)
DIMENSIONS & WEIGHT:
Height: 1774 mm
Width: 902 mm
Depth: 752 mm
To allow product handling and sufficient air circulation, leave at least 10 mm clearance at the sides,
above the appliance and between the rear panel and the wall.
Weight Gross: 146 kg
Weight Net: 140 kg
CAPACITIES / VOLUME:
Gross Volume Net Volume
Fridge: 340 litre 335 litre
Freezer: 206 litre 155 litre
Freezing Capacities 24 hrs 12 kg
Conservation Time 5 hours
Introduction Date
Colours June 2007 July 2007 July 2008
Polar White
MSZ801DF
Silver MSZ802DF
Stainless Steel MSZ803DF
Black MSZ806DF
Suffix 'DF' = dispenser models
