15.4-inch, WXGA display specifications
Metric U.S.
Dimensions
Height
20.7 cm 8.15 in
Width 33.1 cm 13.03 in
Diagonal 39.1 cm 15.39 in
Number of colors Up to 16.8 million
Contrast ratio 200:1 (typical)
Brightness 180 nits (typical)
Pixel resolution
Pitch
0.259 × 0.259 mm
Format 1440 × 900
Configuration RGB vertical stripe
Backlight CCFT
Character display 80 × 25
Total power consumption 6.5 W
Viewing angle +/-45° horizontal, +15/-35° vertical (typical)
104 Chapter 6 Specifications
