3. Remove the speaker assembly (3).
Reverse this procedure to install the speaker assembly.
USB/Media Card Reader board
NOTE: This section applies only to HP Compaq 6715b and 6710b computer models.
Description Spare part number
USB/Media Card Reader board (includes USB/Media Card Reader board cable) 443883-001
Before removing the USB/Media Card Reader board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 48).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 52)
b. Memory/WLAN module compartment cover (see
Expansion memory module on page 56)
c. Optical drive (see
Optical drive on page 62)
d. Keyboard (see
Keyboard on page 64)
e. Switch cover (see
Switch cover on page 70)
f. Display assembly (see
Display assembly on page 76)
g. Top cover (see
Top cover on page 81)
86 Chapter 4 Removal and replacement procedures
