Display assembly
Description Spare part number
15.4-inch, WSXGA+ display assembly for use with HP Compaq 6715b and 6710b computer models
with WWAN capability
443814-001
15.4-inch, WXGA display assembly for use with HP Compaq 6715b and 6710b computer models
with WWAN capability
443817-001
15.4-inch, WXGA, BrightView display assembly for use with HP Compaq 6715b and 6710b computer
models without WWAN capability
443816-001
15.4-inch, WSXGA+ display assembly for use with HP Compaq 6715b and 6710b computer models
without WWAN capability
443813-001
15.4-inch, WXGA display assembly for use with HP Compaq 6715b and 6710b computer models
without WWAN capability
443815-001
15.4-inch, WXGA, BrightView display assembly for use with HP Compaq 6715s and 6710s computer
models
443812-001
15.4-inch, WSXGA+ display assembly for use with HP Compaq 6715s and 6710s computer models 443818-001
15.4-inch, WXGA display assembly for use with HP Compaq 6715s and 6710s computer models 443819-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 48).
5. Remove the memory/WLAN module compartment cover (see
Expansion memory module
on page 56).
6. Disconnect the wireless antenna cables from the WLAN module (see
WLAN module on page 58).
7. Remove the following components:
a. Keyboard (see
Keyboard on page 64)
b. Switch cover (see
Switch cover on page 70)
Remove the display assembly:
1. Disconnect the display panel cable (1) from the system board.
76 Chapter 4 Removal and replacement procedures
