WWAN module (see
WWAN module on page 68)
●
Processor (see
Processor on page 74)
●
PC Card/audio board assembly (see
PC Card/audio board assembly on page 91)
●
Modem module (see
Modem module on page 92)
●
SIM slot board (see
SIM slot board on page 94)
Reverse the preceding procedure to install the system board.
PC Card/audio board assembly
Description Spare part number
For use with HP Compaq 6715b and 6710b computer models 443889-001
For use with HP Compaq 6715s and 6710s computer models 443888-001
Before removing the PC Card/audio board assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 48).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 52)
b. Memory/WLAN module compartment cover (see
Expansion memory module on page 56)
c. Optical drive (see
Optical drive on page 62)
d. Keyboard (see
Keyboard on page 64)
e. Switch cover (see
Switch cover on page 70)
f. Fan (see
Fan on page 71)
g. Heat sink (see
Heat sink on page 72)
h. Display assembly (see
Display assembly on page 76)
i. Top cover (see
Top cover on page 81)
j. System board (see
System board on page 88)
Component replacement procedures 91
