Speaker assembly
Description Spare part number
Speaker assembly 443821-001
Before removing the speaker assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 48).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 52)
b. Memory/WLAN module compartment cover (see
Expansion memory module on page 56)
c. Optical drive (see
Optical drive on page 62)
d. Keyboard (see
Keyboard on page 64)
e. Switch cover (see
Switch cover on page 70)
f. Display assembly (see
Display assembly on page 76)
g. Top cover (see
Top cover on page 81)
Remove the speaker assembly:
1. Disconnect the speaker cable (1) from the PC Card/audio board assembly.
2. Remove the two Phillips PM2.5×5.0 screws (2) that secure the speaker assembly to the base
enclosure.
Component replacement procedures 85
