HP Compaq Elite 8300 User Manual

Stand
The stand is secured with two captive Torx screws. You must remove a plastic cover to gain access
to the screws. You must remove the access panel to remove the stand.
To remove the stand:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 38).
2. Remove the access panel (see
Access panel on page 42).
3. Push the release button (1) on the bottom of the stand and pull the back of the stand off (2).
Figure 7-9 Removing the back of the stand
4. Push the base of the stand down (1), and loosen the two captive Torx screws securing the stand
to the chassis (2).
Figure 7-10 Releasing the stand
44 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis

HP Compaq Elite 8300 Specifications

General

Operating temperature (T-T)	10 - 35 °C
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
HDD size	3.5 \
Dimensions (WxDxH)	178 x 445 x 448 mm
Microphone in	Yes
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
PCI slots	3
Chassis type	Mini-Tower
Product type	PC barebone
Product color	Gray
Audio system	HD
Motherboard chipset	Intel® Q77 Express
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Power supply	320 W
Operating system installed	No
Processor model	-
Processor family	Intel

Weight and Dimensions

Weight	11200 g
