Removal and Replacement Procedures
Maintenance and Service Guide 6–3
6.2 Disassembly Sequence Chart
Use the chart below to determine the section number to
be referenced when removing computer components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the Computer for
Disassembly
Battery pack 0
5.4 Hard Drive 2 loosened to remove the
hard drive cover
1 loosened to remove
the hard drive
6 to disassemble hard drive
5.5 Computer Feet 0
5.6 Bluetooth Board 0
5.7 MultiBay II Device 1
5.8 External Memory Module 1 loosened to remove the
memory module
compartment cover
5.9 Keyboard 3
5.10 Switch Cover 3
5.11 LED Board 5
5.12 TPM Security Module 1
5.13 Fan 2 loosened
5.14 Heat Sink 4 loosened
To Next Page
