Product Description
Maintenance and Service Guide 1–13
Table 1-4
Rear Panel Components
Item Component Function
1 External monitor port Connects an optional external monitor or
overhead projector.
2 Power connector Connects an AC adapter or an optional
automobile or aircraft adapter.
3 S-Video-out jack Is a 7-pin, dual-purpose jack.
It connects an optional S-Video device
such as a television, VCR, camcorder,
overhead projector, or video capture card
by means of an optional, standard (4-pin)
S-Video cable.
The extra 3 pins also enable an optional
S-Video-to-composite adapter to be used
with the computer.
