6–20 Maintenance and Service Guide
Removal and Replacement Procedures
6.10 Switch Cover
1. Prepare the computer for disassembly (Section 6.3).
2. Release the keyboard (Section 6.9).
3. Lift up the left and right hinge cover sections 1 of the switch
cover to detach the cover from the computer.
4. Swing the rear edge of the hinge cover 2 up and forward
until the cover rests on the computer. (The LED board cable
is now visible at the upper-left edge of the computer.)
Removing the Switch Cover
Switch Cover Spare Part Number Information
Switch cover 379794-001
