Removal and Replacement Procedures
Maintenance and Service Guide 6–25
6.14 Heat Sink
1. Prepare the computer for disassembly (Section 6.3).
2. Release the keyboard (Section 6.9).
3. Remove the fan (Section 6.13).
4. Loosen the four PM2.0×8.0 shoulder screws that secure the
heat sink to the computer.
Loosening the Heat Sink Screws
Heat Sink Spare Part Number Information
Heat sink (includes thermal paste) 379799-001
To Next Page
