Product Description
Maintenance and Service Guide 1–21
Table 1-8
Bottom Components
Item Component Function
1 Primary battery bay Holds the primary battery pack.
2 Primary battery locking
latch
Secures the primary battery pack into
the battery bay.
3 Travel battery connector Connects an optional travel battery.
4 Expansion memory
module compartment
Accepts one optional memory module.
5 Hard drive bay Holds the primary hard drive.
6 Docking connector Connects the computer to an optional
docking device.
7 Primary battery release
latch
Releases the primary battery pack from
the battery bay.
8 Vents (3) Enable airflow to cool internal
components.
Ä
To prevent overheating, do
not obstruct vents. Using the
computer on a soft surface, such
as a pillow, blanket, rug, or thick
clothing, may block airflow.
