HP D2D Installation And Configuration Guide

• The HP D2D4300 Series Backup System also has two 10Gb Ethernet ports and, after installation
and discovery, is normally connected to a 10Gb network for backup and replication activities.
(The 1Gb network connection is still required for the Web Management Interface.) On no
account should an HP D2D4300 Series be connected to a 100 or 10 Base-T Ethernet
connection.
• When connecting to a Fibre Channel network, the HP StoreOnce Backup System is supplied
with the correct FC card pre-installed. Cables are not supplied.
• For backup and restore to Virtual Tape Library targets you need software that supports tape
libraries and autoloaders. This software resides on the host, not the HP StoreOnce Backup
System. The device may be used with the major backup applications from HP, Symantec,
EMC, Computer Associates and others.
Supported Ethernet configurations
The HP StoreOnce Backup System supports both IPv4 and IPv6.
The HP StoreOnce Backup System should be connected to a spare port on an existing 1Gb network
switch. This may be your main network, which is also used to connect a number of different types
of devices, such as PCs, servers, workstations and printers, or a dedicated backup network that is
used solely for clients that need to be backed up.
The HP StoreOnce Backup System should be on the same logical and physical network as the host
machine connecting to it. The 1Gb LAN port must always be connected, even if you are using the
FC ports to back up and restore data to the HP StoreOnce Backup System, because the Web
Management Interface requires a 1Gb Ethernet connection to set up devices.
HP D2D4300 Series only
The HP StoreOnce D2D4300 Series Backup System has two 1Gb ports and two 10Gb ports. You
must connect to the 1Gb port (labelled LAN port 3) to run the Installation Wizard and discover
the HP StoreOnce Backup System on your network. This is also the recommended port for running
the Web Management Interface.
The 10Gb ports are available for backup and replication traffic. They must be configured separately,
after installation on the Network (Configuration) page of the Web Management Interface.
Supported Fibre Channel connections
NOTE: Fibre Channel is not supported on models in the HP D2D2500 Series or the HP D2D4106i
Backup System.
The HP StoreOnce Backup System supports both switched fabric and direct attach (private loop)
topologies. A direct attach (point-point) topology is not supported.
A switched fabric topology utilizes one or more fabric switches to provide a flexible configuration
between several Fibre Channel hosts and Fibre Channel targets such as HP StoreOnce Backup
Systems.
Switched fabric configurations are implemented with Fibre Channel switches. Switches may be
cascaded or meshed together to form larger fabrics.
A direct attach topology is implemented by connecting the HP StoreOnce Backup System directly
to a Host Bus Adapter (HBA). In this configuration the Fibre Channel private loop protocol must
be used.
The preferred topology for the HP StoreOnce Backup System is switched fabric using NPIV (N_Port
ID Virtualisation).
Supported Ethernet configurations 7
