Introducing the Switch
Front of the Switch
Front of the Switch
HP E2620-48 Switch (J9626A)
Power
and Fault
LEDs
RPS, Fan and Test
Status LEDs
Switch port LEDs
LED Mode select button
and indicator LEDs
Reset and Clear
buttons
10/100Base-TX RJ-45 ports
1
Uplink ports
(1000Base-T
2
and mini-GBIC)
Console
Port
HP E2620-48-PoE+ Switch (J9627A)
Reset and Clear
buttons
LED Mode select button
and indicator LEDs
10/100Base-TX RJ-45 ports
1
Uplink ports
(1000Base-T
2
and Mini-GBIC)
Switch port LEDs
RPS, EPS, Fan and
Test Status LEDs
Power
and Fault
LEDs
Console
Port
HP E2620-24 Switch (J9623A)
1
All 10/100Base-TX RJ-45 ports have the Auto-MDIX feature.
2
Two RJ-45 10/100/1000Base-T ports and two Mini-GBIC (SFP) slots.
Console
Port
Reset and Clear
buttons
Switch port LEDs
LED Mode select button
and indicator LEDs
10/100Base-TX RJ-45 ports
1
Uplink ports
(1000Base-T
2
and Mini-GBIC)
RPS and Test
Status LEDs
Power
and Fault
LEDs
