Power button board

Description Spare part number

Power button board (includes cable) L28661-001

Before removing the power button board, follow these steps:

1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

4. Remove the bottom cover (see Bottom cover on page 29).

5. Remove the battery (see Battery on page 31).

6. Remove the system board (see System board on page 49).

Remove the power button board:

1. Remove the three Phillips M2.5×4.5 screws (1) from the right hinge.

2. Rotate the hinge upward (2).

3. Lift the Mylar from on top of the board (1).

4. Remove the two Phillips M2.0×3.0 screws (2) that secure the board to the computer.

54 Chapter 5 Removal and replacement procedures for authorized service provider parts
