HP EliteOne 800 G1 Service Manual

WLAN module
Description Spare part number
HP WLAN 802.11 a/g/n, 2x2 701398-001
HP WLAN 802.11 a/b/g/n, 2x2 695915-001
The WLAN module is located on the left side of the system board. The module is secured with one
Phillips screw and has two connected antennas.
NOTE: The procedure to replace the WLAN module must be performed by an HP technician.
NOTE: WLAN module appearance may vary.
To remove the WLAN module:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 34).
2. Remove the access panel (see
Access panel on page 40).
3. Disconnect the antenna cables from the module (1).
4. Remove the Phillips screw (2) that secures the module to the computer.
56 Chapter 5 Removal and Replacement Procedures All-in One (AIO) Chassis
