Card reader board
Description Spare part number
Card reader board 732504-001
The card reader board is located on the right side of the system board. You must remove the system
board before you can remove the card reader board. The card reader board is secured with two
screws.
To remove the card reader board:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 34).
2. Remove the access panel (see
Access panel on page 40).
58 Chapter 5 Removal and Replacement Procedures All-in One (AIO) Chassis
