System board
NOTE: The system board spare part kit includes replacement thermal material.
Description Spare part number
Equipped with Intel HM65 chipset and Intel Core i7-2677M 1.8-GHz processor (4.0-
MB L3 cache, 17 W)
675516-001
Equipped with Intel HM65 chipset and Intel Core i5-2467M 1.60-GHz processor (3.0-
MB L3 cache, 17 W)
675517-001
Thermal Material Kit (includes replacement thermal material) 675515-001
Before removing the system board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 31).
5.
Remove the solid-state drive connector board cable (see
Solid-state drive on page 33).
6. Remove the Card Reader board cable (see
Card Reader board cable on page 35).
7. Remove the top cover (see
Top cover on page 38).
8. Disconnect the RTC battery cable from the system board (see
RTC battery on page 47).
9. Remove the wireless audio module (see
Wireless audio module on page 49).
10. Remove the WLAN module (see
WLAN module on page 51).
When replacing the system board, be sure that the following components are removed from
the defective system board and installed on the replacement system board:
●
Fans (see
Fan on page 53)
●
Memory module (see
Memory module on page 57)
●
Heat sink (see
Heat sink on page 58)
Remove the system board:
1.
Disconnect the webcamera/microphone module cable (1) from the system board.
2.
Disconnect the display panel cable (2) from the system board.
Component replacement procedures
55
